DT Patriot Top/Bottom Mount Pivot With Attached U-Clamp For 3/8″ Glass

SKU: PAT07

Add to wishlist
Compare
13 People watching this product now!

Fast Shipping

Carrier information

20k products

Payment methods

24/7 Support

Unlimited help desk

2-day Delivery

Track or off orders

Additional information
WeightN/A
Select Your Color/Finish
Case Quantity
Catalog Page
Compare To
Item No
Product Name
Weight

Description

Patriot Pivot With an Attached U-Clamp

This DT Patriot Series pivot (item PAT07SB) mounts at the top or bottom of a frameless shower door and includes an attached U-clamp that grips 3/8-inch glass. The clamp holds the glass edge while the pivot carries the swing, and it comes in satin brass.

The built-in U-clamp saves a step by combining the pivot and the glass clamp in one piece, which suits a Patriot Series door that pivots from the top and bottom rather than from a side hinge. This DT part compares to PPH07SB.

Key Product Features

  • Top and bottom mount pivot for 3/8-inch glass
  • Attached U-clamp grips the glass edge
  • DT Patriot Series, item PAT07SB
  • Satin brass finish
  • Compares to PPH07SB

Finish

The satin brass finish carries a warm, matte tone. Clean with a soft, damp cloth and steer clear of abrasive cleaners to protect the finish.

Ordering and Shipping

Listed on page 40 of the FSH24 catalog. Sign in to see current pricing.
